DS-2CD1347G0-L

Camera

• Image Sensor 1/2.7″ Progressive Scan CMOS
• Min. Illumination Color: 0.001 Lux @ (F1.0, AGC ON)
• Shutter Speed 1/3 s to 1/100,000 s
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
• Slow Shutter Yes
• P/N P/N
• Wide Dynamic Range 120 dB
  Lens
• Lens Type & FOV
• 2.8 mm, horizontal FOV 102°, vertical FOV 54°, diagonal FOV 121°
• 4 mm, horizontal FOV 80°, vertical FOV 43°, diagonal FOV 95°
  Aperture F1.0
• Lens Mount M12
• Aperture Type Fixed
• Depth of Focus
• 2.8 mm: 3.1 m to ∞
• 4 mm: 3.6 m to ∞

Illuminator

• Smart Supplement Light Yes
• Supplement Light White
• White Light Range Up to 30 m

Video

• Main Stream
• 50Hz: 20 fps (2560 × 1440)
• 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
• 60Hz: 20 fps (2560 × 1440)
• 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
• Sub Stream
• 50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
• 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
  * Note: The frame rate of the sub-stream cannot exceed the maximum frame rate of
• the current main stream.
• Video Compression
• Main stream: H.265+/H.265/H.264+/H.264
• Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate 32 Kbps to 8 Mbps
• H.264 Type Base Line Profile/Main Profile/High Profile
• H.265 Type Main Profile
• Region of Interest (ROI) 1 fixed region for main stream

Network

• Simultaneous Live View Up to 6 channels
• API ONVIF (PROFILE S), ISAPI, SDK
• Protocols
  TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP,
  QoS, IPv6, UDP, Bonjour, SSL/TLS
  User/Host Up to 32 users. 3 user levels: administrator, operator and user

Security

• Password protection, complicated password, HTTPS encryption, IP address filter,
• security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and
• digest authentication for ONVIF
• Client iVMS-4200, Hik-Connect, Hik-Central
• Web Browser
• Plug-in required live view: IE 10, IE 11
• Local service: Chrome 57.0+, Firefox 52.0+


• Day/Night Switch Day, Night, Auto, Schedule
• Image Enhancement BLC, HLC, 3D DNR
• Image Settings
• Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance

adjustable by client software or web browser
Interface

• Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
• Intelligent (Traditional Algorithm)

Basic Event Motion detection, exception (illegal login)
General

• Linkage Method
• Upload to FTP/NAS, notify surveillance center, send email, trigger recording, trigger
• capture
• Web Client Language
• 2 languages
• English and Ukraine
• General Function Anti-flicker, heartbeat, mirror, privacy masks, password reset via e-mail
• Software Reset Reset via web browser and client software
• Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating
• Conditions    -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Power Supply 12 VDC ± 25%, PoE: 802.3af, Type 1 Class 3, reverse polarity protection
• Power Consumption and
• Current
  12 VDC, 0.37 A, max. 4.5 W
• PoE (802.3af, 36 V to 57 V), 0.13 A to 0.08 A, max. 4.5 W
• Power Interface Ø 5.5 mm coaxial power plug
• Camera Dimension Ø 110 × 100.8 mm (Ø 4.3″ × 4.0″)
• Package Dimension 150 × 150 × 141 mm (5.9″ × 5.9″ × 5.6″)
• Camera Weight Approx. 350 g (0.8 lb.)
• With Package Weight Approx. 556 g (1.2 lb.)

Approval

• EMC
• FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN
• 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC
  (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
  Safety
• UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
• CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS
  13252(Part 1):2010+A1:2013+A2:2015)
• Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection Ingression protection: IP67 (IEC 60529-2013
