DS-2CE76D0T-EXIPF 2.8mm

Resolution

2MP (1920 × 1080 resolution) Indoor EXIR Fixed Turret Camera

IR Range

Up to 20m IR distance for bright night imaging

Protection

IP66 (Water & Dust Resistance)

Frame Rate

TVI: 1080p@25fps/30fps

AHD: 1080p@25fps/30fps

CVI: 1080p@25fps/30fps

Smart Features

DWDR, BLC, D-WDR, Day & Night with ICR

Video Output Mode

4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)

Function

Brightness, Sharpness, Mirror, Smart IR

Field Of View

Horizontal FOV: 102°

Vertical FOV: 55°

Diagonal FOV: 123°

Camera
Image Sensor	2 MP CMOS
Signal System	PAL/NTSC
Resolution	1920 (H) × 1080 (V)
Frame Rate	TVI: 1080p @ 25fps/30fps AHD: 1080p @ 25fps/30fps CVI: 1080p @ 25fps/30fps CVBS: PAL/NTSC
Min. Illumination	0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time	PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Lens	2.8 mm Lens
Field of View	Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 123°
Lens Mount	M12
Day & Night	ICR
WDR (Wide Dynamic Range)	Digital WDR
Angle Adjustment	Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Menu
Image Mode	STD/HIGH-SAT
AGC	Yes
Day/Night Mode	Auto/Color/BW (Black and White)
White Balance	Auto
AE (Auto Exposure) Mode	DWDR, BLC, Global
Noise Reduction	2D DNR
Language	English
Function	Brightness, Mirror, Smart IR, Sharpness
Interface
Video Output	Switchable TVI / AHD / CVI / CVBS
General
Operating Conditions	-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Power Supply	12 VDC ± 25%
Consumption	Max. 3.3 W
Material	Plastic
IR Range	Up to 20 m
Communication	HIKVISION-C
