DB60

5 Megapixel progressive CMOS

5MP(2560 x 1920)

Night Vision: 5m(16.5ft) distance2.0mm

fixed lens

Field of View: 164°

Wi-Fi:IEEE802.11b/g/n,2.4GHz

Imou life app:IOS,Android

Video Compression: H.265

Audio Compression: AAC

Up to 15fps Frame Rate

Two-way Bidirectional Talk Echo

cancellation

Built-in Mic & Speaker Reset

button

Micro USB power port

Call Notification

Motion Detection

Human Detection

Configurable Detection Area

AC12~24V, DC12/24V Power supply

6200 mAh battery

Power Consumption: <0.7A

Surface mounted

Working Environment: -20℃-+50℃, Less than 95%RH

CE EMC,CE RED,CE LVD,FCC,FCC ID,IC,ICID

– Doorbell ×1

– Mounting Bracket ×1

– Angled Bracket ×1 (15° horizontally)

– Angled Bracket×1 (5° vertically)

– Extension Wire ×2

– Charging Cable ×1

– Wire Nuts ×3

– Mounting Screws ×4

– Wall Anchors ×4

– Mounting Screws ×4

– Terminal Screws ×2

– Quick Start Guide ×1

– Pin ×1

– 15/64″ Drill Bit ×1
